Y Strainer
DN40-500

Specification

Size Range: DN40-500
Pressure Class: PN10/16
Medium: Drinking and neutral water up to 70°C

Design: DIN3202-F1

Flange connections: EN1092-2
Pressure test: EN12266

Features

– Designed according to recognized standards

– Bonnet and cover with Stainless steel bolting

– 100% testing before packing and delivery

– Coated with FB epoxy minimum 250 μm thickness
